10 Huge Wi-Fi Antenna Mistakes

Antennas are undervalued and poorly understood elements in WLAN networks. Even Apple is prone to making huge mistakes. Remember the famous “Antennagate” scandal that came about as a result of poor antenna placement and design on their new iPhone? As Steve Jobs pointed out, antenna problems are not unique to iPhone or Apple. This is why everyone and every company needs to learn more about how to position a Wi-Fi antenna. Many times, the Wi-Fi antenna position is the root of Wi-Fi performance problems.

Thankfully, there are common sense things we can follow in order to avoid Wi-Fi issues. Let’s learn how to position a Wi-Fi antenna and the 10 most common antenna mistakes, plus their impact on the end user Wi-Fi experience.

Poor antenna placement


Incorrect Router Antenna Position

1. Partially Covered

  • Access point integrated dipole antennas stick partially through a small hole in a metal ceiling panel, AP cover or metal grid.

  • Outcome: The antenna element has detuned and part of the energy is now directed upwards. Antennas protruding halfway in this manner create a total mess.

2. Unknown Materials

  • An antenna element is placed on top of a ceiling panel made of unknown material with ɛr > 1.

  • Outcome: Antenna is detuned to another frequency, the radiation pattern and impedance matching are altered at the target operating frequency. Antenna gain becomes attenuation.

3. Incorrect Installation

  • Access points with sideways gain patterns and designed for ceiling mounting are installed on a wall.

  • Outcome: The gain goes up and down, amplifying interference and decreasing signal levels.

Incorrect Directional Wi-Fi Antenna Position

4. Close To Metal

  • Access points with integrated omni-directional antennas (where the max gain is sideways) are placed among or above metal air ducts, grids and large lamp reflectors.

  • Outcome: A lot of reflections and refractions cause multiple copies of the signal to arrive at receivers, thereby dropping the data rates. As the radio waves reflect in random directions, the signal strength suffers at both ends.

5. Standard Antenna Placed Too High

  • Access points with standard omni-directional antennas are placed on high ceilings meaning 4-5 meters high (13-16 feet.)

  • Outcome: Most of the energy is directed sideways towards other access points causing co-channel interference. Also, antenna gain shoots over the target area and data rates are reduced.

6. High Gain Antenna Placed Too High

  • Directional, high gain omni-directional Wi-Fi antennas are used and placed on a high ceiling.

  • Outcome: These antennas have narrow beams pointing sideways, therefore, significant overshooting and even more co-channel interference takes place.

We've put together a comprehensive guide on antenna placement and we invite you to download it by clicking below.

Get Antenna Placement Guide


7. Positioned Next To Thick Wall

  • Access points with omni-directional antennas are placed next to a thick wall.

  • Outcome: Half of the antenna's gain is lost as the antenna tries to pick up signals from the wall, which is an unused direction.

Other Wi-Fi Antenna Mistakes

8. Metallic Paint

  • Antennas are painted with a metallic paint.

  • Outcome: Signal attenuation due to the conductive surface.

9. Metal Enclosures

  • End user terminals (such as laptops) are placed in metal enclosures, like carts.

  • Outcome: the proximity of the conductive material causes antenna detuning and the energy cannot radiate outside the box. A very large attenuation in signal levels is the result (>10 dB).

10. Human Interference

  • Often it is forgotten in network planning that VoIP terminals are placed against the human head with a hand covering the other side.

  • Outcome: Site surveys with laptop card and standard limits give completely different results.

Now that we know how to position Wi-Fi antennas, there are some rules of thumb that help with getting good performance out of antennas:

  • Larger antennas have typically better performance than smaller ones. Gain/directivity is not available from a very small surface area.

  • Know and understand your antenna radiation patterns. Point antennas gain towards users.

  • Make antennas visible to end users, do not hide them above the ceiling grid.

  • Do not place anything conductive near antennas. Allow three full feet of distance, preferably more.

  • Use good quality external antennas, as the integrated antennas often have been compromised for design, though there are some exceptions.

  • Simple dipole antennas or four-six leg spider-like APs are rarely an optimal selection.

Wi-Fi Implementation

Finally, it is fun and entertaining to visit public places and observe the “innovations” in WLAN implementations. On a rare occasion, there are some pretty good ones!

One funny story was where a prison inmate was using a Playstation WLAN to communicate with others outside the prison. What made this innovation entertaining was the fact that he was using a large frying pan lid as a reflector to increase antenna gain and achieve the range needed for connectivity. Talk about creativity!
